Building Specifications

• 40.000 m²

• 30.000 m²

• Approx. 1.500 m² / floor

• 25 levels and 4 basements

• Column free with center core

• Integrated Building Management System (IBMS)

• 100% of the building for 24 hours

• Water-cooled chillers, Air conditioning capacity inside premises: 115 W/m2.
• High performance using high efficiency chillers (targeting 131 kWh/m2 per annum or 36% less than the benchmark average usage)

• Special dual-skin building façade with a sun-shading louver in between, minimizing any external noise and heating
• Highly energy efficient
• Also acts as a day lighting control

• From 2.5 kN/sqm to 5 kN/sqm (subject to localized areas)

• 2.75 m from raised finished floor to suspended ceiling

• Fully raised flooring, 100 mm

12 Lifts – ThyssenKrupp including:

• Office Lift: 8 lifts high speed with destination control for low zone from level 1 to level 12 & high zone from level 14 to level 24, in which 2 designated high speed lifts for 2 office levels on level 25 & 26 go down to basement 3
• Shuttle lift: 2 lifts from Basement 4 to Level 2
• Fire/service lift: 1 lift from Basement 4 to level 26
• 1 lift from level 1 to level 6 separated for German Consulate General

• Customized entrance security with proven, compatible access control technology

• 500 Lx (international Grade A + office standard)

• 179 parking spaces for cars and more than 1,171 parking spaces for motorbikes in the basements

• 3 x 427 RT chillers for office floors

• 2 main line medium voltage feeders (22kv) from local power grid
• 2x2000 KVA and 1x 1600 KVA dry type transformers in basement 1
• 3 stand-by generators with capacity of 2x 2000 KVA and 1x 1600 KVA each as backup for 100% of the building’s requirements including tenants normal usage
